Chamber Size
(HXWXL) |
500x500x1100 |
600x750x1400 |
750x900x1800 |
Bale Size
(HXWXL) |
250x250x200 to 250 |
300x300x250 to 300 |
375x375x350 to 400 |
| Power In H.P. |
10 |
15 |
20 |
Force On Lid
Cylinder In Ton |
40 |
40 |
75 |
Force On Main
Cylinder In Ton |
60 |
75 |
75 |
Force On Side
Cylinder In Ton |
85 |
120 |
150 |
Force On Ejector
Cylinder
In Ton |
10 |
12 |
12 |
| Hard Liner Plates |
Provided |
Provided |
Provided |
| Weight Of The Bale In M.S (Approx)In Kg. |
40 to 60 |
55 to 80 |
65 to 100 |
| Weight Of The Bale In Al. (Approx)In Kg. |
12 to 22 |
20 to 30 |
25 to 40 |
Idle Cycle Time
(Approx) In Sec |
90 |
90 |
90 |
